Syvecs Syvecs X4 Expander

Syvecs Syvecs X4 Expander

£540.00 Inc. VAT £450.00 Exc. VAT

Syvecs Input/Output expansion units are designed to offer more I/O allowing customers to maximises other strategies on the Syvecs range, or allow more sensors/parameters to be logged via Datalogging . CAN Interfaces provide communication to ECU’s or Displays

SKU: SYV-X4 Category:

Description



The Syvecs X4 Expander is a compact but very powerful expansion unit for enhancing the Input and Output compliment of a powertrain electronics installation.

The X4 is fitted with four Half Bridges drivers which are capable of driving Low, High or joined in pairs as a full bridge motor driver. Each of the four H-Bridge Outputs is equipped with a current monitoring circuit which can be assigned in strategies on Syvecs Engine Controllers or as Current Limiting functions in other applications.

Four MagnetoResitive circuits make reading the ABS sensors found on most new automotive applications easier by just needing to connect one side of the sensor to the X4 and the other side to Ground.

The four 0-5v Analog inputs are not capable of frequency detection but are useful for monitoring of switches, pressure transducer or positional sensors.

Able to withstand the toughest of conditions and high temperatures the X4 is useful for many applications whether it’s for external Drive By Wire support, Electronic Wastegates, Fuel Pump Controller and more.

Two canbus interfaces are fitted on the X4 which are setup out of the box for Slave Control with a S7,S8,S12 Ecu or XCan Support for other Ecu’s.

Outputs

4 Half Bridge Outputs (Supports: Full Bridge, Lowside or HighSide Drive)

15Amp Peak (100ms) 8Amp Continuous

Current Monitoring on each pin

Inputs

4 Analogue or switch inputs (0-5V) (Gen2 Version has Optional 3k pull-ups)

4 MagnetoResistive Wheel Speed Sensor Inputs

Interfaces

USB For Updates and Config

2 x CAN 2.0B interface for communication with other controllers or logging systems

1 x Kline Interface

Power Supply

6 to 26V input voltage range

Ignition Switch Logic with high current supply

Physical

IP67 Sealed in Automotive Spec -40c to 125c

34 way Superseal 1.0

89cm x  88mm x 40mm



Additional information

Weight 5 kg
Brand

Syvecs

Part Type

Electronic
